If you are facing difficulties while flashing your Samsung Galaxy S24 Plus SM-S926B or trying to remove the FRP lock, you might find the ISP Pinout for Samsung Galaxy S24+ SM-S926B UFS helpful. While using your tools, you may come across problems while trying to flash stock firmware, remove locks, or bypass factory reset protection.
It is possible to reset user lock FRP, write a UFS dump, and erase the MDM lock on the Samsung Galaxy S24+ Plu using the provided pinout. To learn how to use the Samsung Galaxy S24 Plus UFS ISP Pinout, please refer to the relevant documentation.
By following the tutorial and pictures provided in this guide, you can easily locate the UFS ISP Pinout connection of your Samsung Galaxy S24+ Plus SM-S926B. With the help of the ISP Pinout and EasyJTAG Plus Box or any other tool, you can bypass the FRP lock or reset user data on your device. Simply refer to the step-by-step instructions below to get started.
What is Samsung Galaxy S24+ Plus SM-S926B UFS ISP Pinout?
UFS ISP PinOUT refers to the Universal Flash Storage In-System Programming PinOUT. It is a set of pins on the device’s circuit board that allows direct access to the flash memory. Advanced users and technicians can bypass the typical software interfaces and directly interact with the device’s storage system by connecting to these pins.
Samsung Galaxy S24+ Plus Repair Dead boot, Flashing, remove FRP lock and any brand phone.EasyJTAG Plus is the only box that supports UFS. Some phones need those boxes after flashing the wrong firmware and not booting. If you had those boxes for boot repair, it would be great. Removing a pin, pattern, password, FRP, or MDM lock on some brands is impossible. You can remove locks with this.
Samsung Galaxy S24+ Plus SM-S926B UFS ISP Pinout Image
- First, take your phone’s back cover off. Then, remove the battery, fingerprint reader, and camera from the motherboard.
- Unscrew the screws that hold the motherboard in place, carefully remove it, and put it in a safe place.
- Find the TxOp, TxOn, RxOp, and RxOn pins for the eMMC on the device. You might have to cut through the steel cover to get to them.
- Get the UFI box, then take the adapter out of it. The pins on the adapter should be the same as the ones listed in the last step.
- Between the base and the adapter, use jumpers to connect the four pins (TxOp, TxOn, RxOp, and RxOn). Leave the USB to power the VCC and VCCQ.
- Put the connector into the UFI box and connect the box to your computer.
- Connect the battery to the computer again. Then, connect the phone to your computer using the USB connection.
Required:
- Samsung Galaxy S24+ with Good Charge Battery
- Easy Jtag box with adapter
- Micro USB Cable
- Computer or Laptop
Samsung Galaxy S24+ Plus SM-S926B FRP Lock Using EasyJTAG Plus:
- Remove the device’s back panel and connect the wire to the UFS ISP Pinout.
- Next, connect the correct UFS ISP Pinout to the EasyJTAG Plus box
- Check the “UFS” tab
- Then Click on “Identify UFS Chip.
- Connect your Samsung Galaxy S24+ Plus SM-S926B to the PC via a USB cable.
- Go to Preset Select Persistent
- Now Click on Erase LUN0 Data
