    Samsung Galaxy A30 Charging Ways – Charging Problem Solution

    By
    Here we will discuss Samsung Galaxy A30 A305F Not charging problem, charging ways, and USB jumper, This mobile charging problem does not easily make a bad part, and though it is worse, the charging connector. So this mobile charging problem arises Then first switch the charging connector. And if the problem is not resolved even after the charging connector is changed. If you see the picture that I gave the picture, your jumper. Below I’ll tell you to step by step, how do you solve this problem.
    This mobile charging problem does not easily make a bad part, and though it is worse, the charging connector. So this mobile charging problem arises Then first switch the charging connector. And if the problem is not resolved even after the charging connector is changed. If you see the picture that I gave the picture, your jumper. Below I’ll tell you to step by step, how do you solve this problem.

    Samsung Galaxy A30 A305F Charging Ways Solution

    In the below image we draw the Samsung Galaxy A30 charging ways and its jumper check continuity using a multimeter if any track damage makes a jumper on the Redmi Note 8 Pro motherboard.

    1. First, open the mobile
    2. Then clean the section of the charging connector of the mobile motherboard
    3. Then remove the old charging connector and add a new connector
    After doing this, but the mobile phone in charge once, After doing these things, if the mobile is solved then fitting the mobile, If the problem is not solved after doing these, then I have given a picture below to do the job.
    Samsung Galaxy A30 Charging Ways Charging Problem Solution

    How To Repair Samsung Galaxy A30 Not Charging Problem:

    Samsung Galaxy A30 A305F Charging Ways Charging Jumper Solution Slow Or Fake Charging Solution

    Read More:-  Samsung G531f Power Key Ways - Power Switch Jumper Solution

    After the mobile phone disassembles, you will need to take some steps shown in the diagram above.

    Check the Charging jack and its points do they have good value if yes, then change the changer and check it and if the motherboard does not see the accurate value with the charging points, then after the dissatisfaction of the mobile phone you get something shown in the above diagram You have to take steps.

    Check the Charging jack and its points are good values if yes, then change the changer and check it and if the motherboard does not see the accurate value with charging points, then you will see all the parts and tracks given in the diagram of Samsung Galaxy A30 Are to investigate.

    Below are the most common causes of why you Samsung Galaxy A30 have trouble charging, and other problems concerning the battery like the grey battery issue:

    1. Shorted/faulty diode
    2. Shorted/faulty capacitors
    3. faulty resistors
    4. Bad/damaged charging coil
    5. Shorted/faulty IC
    6. Bad USB Port
    7. Partial contact

    If any corrosion or carbon and water damage or any component are damaged, then the motherboard should be replaced carefully. If a track is lost then the jumper is applied and if any part is damaged or broken, replace it with the new one.

    More information about this problem and solutions for new tips and tricks are going to this page, if there are new updates, there will be updates. Below are some related posts, you can read more about mobile phones.
